Hyundai Santa Fe parts sizes by model year
This site has read 3 owner's manual years for the Hyundai Santa Fe (2017, 2020, 2022). The table puts the main replacement sizes side by side so you can see which years share parts. Open a year for the full list with manual page numbers.
- 1Bulb PY21W
| Year | Wipers (driver / passenger) | Low beam | High beam | Oil filter | Battery |
|---|---|---|---|---|---|
| 2017 | not printed | H7LL | — | — | — |
| 2020 | not printed | HB3 | — | — | — |
| 2022 | not printed | — | — | — | — |
Year by year
- 2017: the manual prints bulbs and oil, with 12 bulb numbers and 6 LED positions.
- 2020: the manual prints bulbs and oil, with 11 bulb numbers and 10 LED positions; changed from 2017: low-beam bulb.
- 2022: the manual prints bulbs, with 6 bulb numbers and 12 LED positions.
Generations covered
The Santa Fe years on this site span 2 generations: 3rd gen (DM) — Santa Fe Sport (2-row) & Santa Fe LWB (3-row) and 4th gen (TM). Parts such as bulbs and wiper arms usually change at a new generation and sometimes at a mid-cycle refresh, which is where the table above tends to change.
Bulb numbers across the years
| Bulb | Printed as | Positions | Years |
|---|---|---|---|
| PY21W | PY21W | front turn signal lamp and rear turn signal lamp | 2017, 2020, 2022 |
| W16W | W16W | back up lamp and reverse lamp | 2017, 2020, 2022 |
| W5W | W5W | front marker lamp, rear marker lamp, license plate lamp and tail lamp | 2017, 2020, 2022 |
| P21/5W | P21/5W | tail/stop lamp | 2020, 2022 |
| D1S | D1S | headlamp low | 2017 |
| H7 | H7LL | headlamp low and headlamp high | 2017 |
| H8 | H8 | fog lamp | 2020 |
| HB3 | HB3 | headlamp low and headlamp high | 2020 |
| P27/7W | P27/7W | rear turn signal lamp | 2017 |
| P28/8W | P28/8W | stop/tail lamp and tail lamp | 2017 |
| PY28/8W | PY28/8W | front turn signal lamp | 2017 |
| PY28W | PY28W | front turn signal lamp | 2020 |
The PY21W is also listed by 9 other models on this site, including the Ford Transit, Hyundai Elantra and Hyundai Tucson. The W16W is also listed by 20 other models on this site, including the Chevrolet Trax, Ford Transit and Hyundai Elantra. The W5W is also listed by 33 other models on this site, including the Chevrolet Equinox, Chevrolet Trax and Ford Escape. The P21/5W is also listed by 7 other models on this site, including the Ford Transit, Hyundai Elantra and Hyundai Tucson. A shared number is the same replacement bulb, whichever car it came from.
Reading the table
A dash means the Santa Fe manual for that year does not print the value, not that the part does not exist. Makers differ in what they print: some list wiper lengths and filter part numbers, others list only bulbs. Where a cell changes from one year to the next, the part changed in the manual too, often at a new generation or a mid-cycle update.
Generations covered start with the 3rd gen (DM) — Santa Fe Sport (2-row) & Santa Fe LWB (3-row). See each year page for the generation it belongs to.
