Cars › Chevrolet Trax
Chevrolet · 2015–2022, 2024–2026
Chevrolet Trax parts sizes by model year
This site has read 11 owner's manual years for the Chevrolet Trax (2015–2022, 2024–2026). The table puts the main replacement sizes side by side so you can see which years share parts. Open a year for the full list with manual page numbers.
- 1Back Up Lamps W16W
| Year | Wipers (driver / passenger) | Low beam | High beam | Oil filter | Battery |
|---|---|---|---|---|---|
| 2015 | 650 / 380 mm | H11 LL | 9005LL | PF2257G | — |
| 2016 | 650 / 380 mm | H11 LL | 9005LL | PF2257G | — |
| 2017 | 650 / 380 mm | H11LL | HB3LL | PF2257G | — |
| 2018 | 650 / 380 mm | — | — | PF2257G | — |
| 2019 | 650 / 380 mm | — | — | PF2257G/PF2263G | — |
| 2020 | 650 / 380 mm | — | — | PF2257G/PF2263G | — |
| 2021 | 650 / 380 mm | — | — | PF2257G/PF2263G | — |
| 2022 | 650 / 380 mm | — | — | PF64 | — |
| 2024 | 600 / 450 mm | — | — | PF64 | — |
| 2025 | not printed | — | — | — | — |
| 2026 | not printed | — | — | — | — |
Year by year
- 2015: the manual prints wipers, bulbs and filters, with 6 bulb numbers.
- 2016: the manual prints wipers, bulbs and filters, with 6 bulb numbers; same wiper blade lengths, low-beam bulb, high-beam bulb, oil filter and cabin air filter as 2015.
- 2017: the manual prints wipers, bulbs and filters, with 6 bulb numbers; changed from 2016: high-beam bulb.
- 2018: the manual prints wipers and filters; same wiper blade lengths, oil filter and cabin air filter as 2017.
- 2019: the manual prints wipers and filters; changed from 2018: oil filter.
- 2020: the manual prints wipers and filters; changed from 2019: oil filter.
- 2021: the manual prints wipers and filters; changed from 2020: oil filter.
- 2022: the manual prints wipers and filters; changed from 2021: oil filter.
- 2024: the manual prints wipers, bulbs, filters and oil, with 3 bulb numbers; changed from 2022: wiper blade lengths and cabin air filter.
- 2025: the manual prints bulbs, with 3 bulb numbers.
- 2026: the manual prints bulbs, with 3 bulb numbers.
Generations covered
The Trax years on this site span 2 generations: 1st gen and 2nd gen. Parts such as bulbs and wiper arms usually change at a new generation and sometimes at a mid-cycle refresh, which is where the table above tends to change.
Bulb numbers across the years
| Bulb | Printed as | Positions | Years |
|---|---|---|---|
| W16W | W16W | back-up lamp and back up lamps | 2017, 2024–2026 |
| H11 | H11 LL and H11LL | low-beam headlamp | 2015–2017 |
| W21W | W21W LL | tail/stop/turn | 2024–2026 |
| W5W | W5W LL and W5W | license plate lamp | 2015–2017 |
| WY28/8W | WY28/8W | front turn signal/parking lamps | 2024–2026 |
| 7444 | 7444NA | front parking lamp and front turn signal lamp | 2015–2016 |
| 9005 | 9005LL | high-beam headlamp | 2015–2016 |
| 921 | 921 | back-up lamp | 2015–2016 |
| H8 | H8LL | front fog lamp | 2017 |
| HB3 | HB3LL | high-beam headlamp | 2017 |
| WY21W | WY21W | rear turn signal lamp | 2017 |
The W16W is also listed by 20 other models on this site, including the Ford Transit, Hyundai Elantra and Hyundai Palisade. The H11 is also listed by 25 other models on this site, including the Chevrolet Equinox, Chevrolet Silverado 1500 and Ford Escape. The W21W is also listed by 9 other models on this site, including the Ford Bronco Sport, Ford Escape and Ford Explorer. The W5W is also listed by 33 other models on this site, including the Chevrolet Equinox, Ford Escape and Ford Explorer. A shared number is the same replacement bulb, whichever car it came from.
Reading the table
A dash means the Trax manual for that year does not print the value, not that the part does not exist. Makers differ in what they print: some list wiper lengths and filter part numbers, others list only bulbs. Where a cell changes from one year to the next, the part changed in the manual too, often at a new generation or a mid-cycle update.
Generations covered start with the 1st gen. See each year page for the generation it belongs to.
